DWIN 4.1inch Smart HMI LCD Capacitive Touch, IPS TFT Display 720×720, 400nit, DMG72720C041_03WTC
₹3,991
Out of stock
Specifications
- Color : 16.7M（16777216） colors
- LCD Type : IPS, TFT LCD
- Viewing Angle : Wide viewing angle, 85°/85°/85°/85°（L/R/U/D）
- Display View Area (V.A.) : 75.0mm (W)×75.0mm (H)
- Display Active Area (A.A.) : 74.0mm (W)×74.0mm (H)
- Resolution : 720×720
Description
DWIN 4.1inch SMART HMI LCD Capacitive Touch, IPS TFT Display 720×720, DMG72720C041_03WTC
This is a DWIN 4.1inch SMART HMI LCD Capacitive Touch, IPS TFT Display 720×720, 400Nit, DMG72720C041_03WTC. The Dwin 4.3inch LCD Comes 16.7 Millions Colors With 400nit Brightness, Which Support Capacitive Touch and 720×720 Resolution.
Features
- IPS-TFT-LCD T5L ASIC,16.7M Colors, 24bit,720×720 resolution
- INCELL capacitive touch panel
- Commercial grade; Support point touch and drag
- Download via SD card or on-line serial port
- Easy-to-use DWIN DGUS V7.6 GUIs Development, no coding skills required
- Dual Development System: DGUS II/ TA(Instruction set)
- Wide Viewing Angle: 85°/85°/85°/85° (L/R/U/D)
- 10Pin_1.0mm socket for power supply and serial communication
- Download rate(typical value): 12KByte/sTouch Data
- Type CTP : (Capacitive touch panel）
- Structure : INCELL structure
- Touch Mode : Support point touch and drag
- Light Transmittance : Over 95%
- Life : Over 1,000,000 times touch
- Brightness : 400nitOperating Environment
- Working Temperature : -20℃~70℃
- Storage Temperature : -30℃~80℃
- Working Humidity : 10%~90%RH
- Power Voltage : 4.5~5.5V
- Operation Current : VCC = +5V, Backlight on,220mA / VCC = +5V, Backlight off,70mA
- Output Voltage : Output 1, Iout = 1mA;3.0~3.3 V / Output 0, Iout =-1mA;0~0.3 V
- Input Voltage (RXD : Input 1， Iin = 1mA；2.4~5.0V / Input 0， Iin = -1mA；0~0.5V
