Description

Experience next-generation keyboard computing with the Official Raspberry Pi 500 Desktop Kit (SC1285). Integrating the flagship performance of the Raspberry Pi 5 directly into a sleek, compact keyboard form factor, the Pi 500 delivers 2× to 3× the speed of the earlier Pi 400 generation. Equipped with a custom full-length monolithic aluminum heatsink, the Raspberry Pi 500 operates completely silently without requiring a cooling fan, maintaining continuous peak processing speeds under heavy computing workloads.

This complete Desktop Kit provides everything required to get started straight out of the box—just plug it into any monitor or TV! The bundle includes the official high-speed 27W USB-C PD Power Supply for unthrottled performance, an Official USB Mouse, a 32GB MicroSD Card pre-installed with Raspberry Pi OS, a Micro-HDMI cable, and the full-color Raspberry Pi Beginner’s Guide Book.

---

Technical Specifications

Parameter	Specification
Model Code / Part Number	SC1285 (Official US Layout Complete Kit)
Keyboard Form Factor	Compact 78-Key US Layout Keyboard Computer
Processor Speed	2.4GHz Quad-Core 64-bit ARM Cortex-A76 (Broadcom BCM2712)
I/O Controller & GPU	RP1 I/O Controller | VideoCore VII GPU @ 800MHz
Installed Memory	8GB LPDDR4X-4267 SDRAM
Video Out / Display Ports	2 × Micro-HDMI Ports (Supports Dual 4K@60Hz resolution)
Thermal System	Heavy-duty internal custom aluminum heatsink (Silent, fanless operation)
Wireless Connectivity	Dual-Band (2.4GHz & 5.0GHz) 802.11ac Wi-Fi, Bluetooth 5.0 / BLE
Networking & USB	Gigabit Ethernet (10/100/1000 Mbps) | 2 × USB 3.0, 1 × USB 2.0
Expansion Interface	Rear Horizontal 40-Pin GPIO Header
Power Supply Included	Official Raspberry Pi 27W USB-C Power Adapter (5.1V / 5A PD)
Included Accessories	Official USB Mouse, 32GB MicroSD Card (pre-loaded), Micro-HDMI Cable, Official Beginner’s Guide Book (5th Edition)

---

---

Key Features & Highlights

• Flagship Raspberry Pi 5 Architecture: Powered by a 2.4GHz quad-core ARM Cortex-A76 processor for desktop-class responsiveness, high-speed web browsing, and multi-threaded software execution.

• Silent Thermal Management: Engineered with a continuous internal aluminum heatsink plate that dissipates heat efficiently across the entire chassis without fan noise or thermal throttling.

• Dual 4K Monitor Outputs: Twin micro-HDMI video ports allow you to connect two 4K displays simultaneously at 60Hz.

• Out-of-the-Box Complete Setup: Includes all necessary official power supplies, storage, cables, mouse, and step-by-step instructional literature.

• Accessible Rear GPIO Pin Header: Easily connect sensors, breadboards, expansion HATs, and robotics hardware directly through the exposed 40-pin GPIO slot.

Common Applications

• All-in-one primary PC workstation replacement for home, office, and classroom environments.

• STEM education, learning Python, C++, Scratch programming, and Linux OS management.

• Portable field terminal for software development, hardware prototyping, and electronics tinkering.

• Silent media hub, digital signage controller, or light server node.

---

Why Buy From Aryabot?

• 100% Original Hardware: Sourced directly from official Raspberry Pi distribution networks to guarantee genuine products and maximum reliability.

• Tested & Benchmarked: Quality-checked for port connectivity, keyboard actuation, power supply delivery, and boot stability before shipping.

• GST Invoice Provided: Tax-compliant B2B invoices generated for corporate procurement, educational institutions, and schools.

• Pan-India Express Dispatch: Quick processing and reliable shipping directly from our Noida fulfillment facility.

---

Kit Includes:

1 x Raspberry Pi 500, US

1 x Official 32GB microSD card, pre-programmed with Raspberry Pi OS

1 x Raspberry Pi 27W USB-C Power Supply White US

1 x Raspberry Pi Official Mouse – Red/White

1 x Micro-HDMI to Standard HDMI (A/M), 1m Cable, White

1 x Raspberry Pi Official Beginner’s Guide.
