Water Level Depth Detection Sensor Module
Water Level Depth Detection Sensor Module - Image 2
Water Level Depth Detection Sensor Module - Image 3
Water Level Depth Detection Sensor Module - Image 4
Water Level Depth Detection Sensor Module - Image 5
Water Level Depth Detection Sensor Module - Image 6
Water Level Depth Detection Sensor Module - Image 7
Water Level Depth Detection Sensor Module - Image 8
Water Level Depth Detection Sensor Module - Image 9
Water Level Depth Detection Sensor Module - Image 10
Water Level Depth Detection Sensor Module - Image 11

Water Level Depth Detection Sensor Module

₹26

In stock

  • (GST Bill) Enter your GST number at checkout
  • Free shipping on eligible prepaid orders
  • Secure payments via Razorpay and Paytm
  • Dispatch in 24 Hours from Noida warehouse!
  1. Operating voltage: DC3-5V
  2. Operating current: less than 20mA
  3. Sensor Type: Analog
  4. Detection Area: 40mmx16mm
  5. Operating temperature: 10℃-30℃
  6. Humidity: 10% -90% non-condensing
SKU: SE1714 Categories: ,

Description

The Water Level Depth Detection Sensor Module provides an easy, low-cost solution for detecting liquid level, water volume, and immersion depth. Built on a lightweight double-sided printed circuit board, the sensor features a series of exposed, parallel conductor traces that act as a variable resistor when submerged in water.

As the water level rises along the sensing traces, more conductor lines are bridged by water, lowering the electrical resistance and increasing the analog output voltage. The module operates smoothly on 3.0V to 5.0V DC, making it natively compatible with both 3.3V microcontrollers (ESP32, ESP8266, Raspberry Pi Pico) and 5V microcontrollers (Arduino Uno, Nano, Mega).

Technical Specifications

Parameter Specification
Operating Voltage 3.0V to 5.0V DC
Operating Current Less than 20 mA
Sensor Output Type Analog Output Voltage (0V to VCC proportional to depth)
Detection Area / Sensing Trace Length 40 mm × 16 mm
Working Temperature 10°C to 30°C
Operating Humidity Range 10% to 90% Non-Condensing
Pinout / Interface 3-Pin Header (S – Analog Signal, + – VCC, – – GND)
Module Dimensions 62 mm × 20 mm

Key Features & Highlights

  • Proportional Analog Reading: Output voltage increases linearly as the water level rises along the exposed conductor lines, allowing accurate depth calculations.

  • Low Power Consumption: Draws less than 20mA during active readings, making it suitable for battery-powered remote IoT monitoring nodes.

  • Plug-and-Play Interface: Simple 3-pin header layout fits directly onto standard breadboards or sensor shields using female jumper cables.

  • Wide Microcontroller Compatibility: Works seamlessly with standard microcontroller ADC (Analog-to-Digital Converter) channels without external signal amplifiers.

Common Applications

  • Automatic water tank level monitoring and overflow alarm systems.

  • Smart agricultural irrigation systems and soil drainage tracking.

  • Automated rainfall collection level monitoring in smart weather stations.

  • Aquarium water level maintenance and sump pump triggers.

What’s Included in the Box

  • 1 × Water Level Depth Detection Sensor Board

Why Buy From Aryabot?

  • 100% Quality Hardware: Sourced through trusted manufacturing partners to ensure clean trace etching and accurate analog response.

  • Tested & Benchmarked: Quality-checked for pin continuity, trace insulation, and analog voltage scaling prior to dispatch.

  • GST Invoice Provided: Tax-compliant B2B invoices generated for commercial projects, institutional research labs, and academic orders.

  • Pan-India Express Dispatch: Fast order processing and reliable shipping directly from our Noida fulfillment warehouse.



* Product Images are shown for illustrative purposes only and may differ from actual product.

Additional information

Weight 0.01 kg
Dimensions 6 × 2 × 0.15 cm
